April 4, 2023Product Description
Specification
|
item
|
value
|
|
Type
|
Steel Frame & Purlin Machine
|
|
Applicable Industries
|
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
|
|
Showroom Location
|
None
|
|
Video outgoing-inspection
|
Provided
|
|
Machinery Test Report
|
Provided
|
|
Marketing Type
|
New Product 2020
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
|
|
Condition
|
New
|
|
Work Pressure
|
–
|
|
Production Capacity
|
35-50m/min
|
|
Place of Origin
|
China
|
|
Hebei
|
|
|
Brand Name
|
XN
|
|
Voltage
|
380V 50HZ
|
|
Power
|
5.5kw
|
|
Dimension(L*W*H)
|
5000*800*1600mm
|
|
Weight
|
2.5kg
|
|
Warranty
|
1 Year
|
|
Key Selling Points
|
Easy to Operate
|
|
After-sales Service Provided
|
Online support
|
|
Control System
|
PLC Colored Touch Screen
|
|
Main Frame
|
18mm steel welding
|
|
Shaft Diameter
|
42 mm
|
|
Feeding Thickness
|
0.3-1.5mm
|
|
Cutter Standard
|
GCr12
|
|
Roller Standard
|
45# Plating Cr
|
|
Weight
|
About 2.5T
|
|
Motor power
|
5.5+4 kw
|
|
Certification
|
CE, ISO, BV
|
Packing & Delivery
2. Technical parameters:
| Technical parameters: | |||||||
| 1 | Name of commodity & specification | light gauge steel machine | |||||
| 2 | Main motor power | 3kw, 3 phase | |||||
| 3 | Hydraulic motor power | 3kw | |||||
| 4 | Hydraulic Pressure | 10-12MPa | |||||
| 5 | Voltage | 380V /3phase/ 50 HZ (or as your requirement) | |||||
| 6 | Control System | PLC Delta Inverter | |||||
| 7 | Main Frame | 300mm H-Beam | |||||
| 8 | Backboard Thickness | 14mm | |||||
| 9 | Chain Size | 20mm | |||||
| 10 | Feeding Material | color steel coils | |||||
| 11 | Feeding Thickness | 0.3-1.2mm | |||||
| 12 | Productivity | 8-12m/min | |||||
| 13 | Roll Station | 11 | |||||
| 14 | Roller Diameter | 70mm | |||||
| 15 | Roller material | 45# steel | |||||
| 16 | Cutter material | Cr12 , quenched | |||||
| 17 | Cr-Plating Size | 0.05mm | |||||
| 18 | Overall Size | 3000×800×1000mm | |||||
| 19 | Total Weight | 2T | |||||
| 20 | Components | Manual Uncoiler——————-1 set Guiding Platform——————1 set Coil Strip Leveler——————1 set Main Machine of Roll Forming——1 set Electric-Motor———————1 set Cutting Device——————–1 set Hydraulic Station——————1 set PLC Control———————–1 set Supporter Table——————-1 set |
|||||
| 21 | Workflow | Manual decoiling—-feeding and guiding—-roll forming—-cut to length—-run out table | |||||
| 22 | Package | nude in the container | |||||
| 23 | Minimum order quantity | 1 set | |||||
| 24 | Payment terms | T/T(30% T/T pay in advance, the remaining 70% pay before ship) | |||||
| 25 | Delivery time | 30 working days later after receiving the deposit | |||||
